Specifications
164 Cubis MSU User Manual
Model-specific Data
Precision balances
Models MSU5203S MSU5203P MSU3203S MSU3203P
Readability mg 1 1/2/5 1 1/10
Weighing capacity g 5200 1200/2400/5200 3200 1010/3200
Tare range (subtractive) g - 5200 - 5200 – 3200 – 3200
Repeatability <±mg 1 1 1 1/6
Linearity <±mg 5 5 5 5
Corner load (test load [g]) mg 2 (2000) 2 (2000) 2 (1000) 2 (1000)
Min. initial weight* g 1.5
Sensitivity drift between +10 to +30°C ±ppm/K1 1 1 1
Typical stabilization time s < 1 < 1 < 1 < 1
Typical measurement time s < 2 < 2 < 2 < 1.5
External standard calibration value g 5000 5000 2000 2000 (E2)
(min. accuracy class)
Display result
(depending on the set filter level) 0.1 – 0.4
Weighing pan size (W + D) mm 140 +140
Weighing chamber height mm 172
(draft shield DU)
Protection Protected against dust and water
* = Position according to OIML R76
Models MSU2203S MSU2203P MSU1203S
Readability mg 1 1/10 1
Weighing capacity g 2200 1010/2200 1200
Tare range (subtractive) g – 2200 – 2200 – 1200
Repeatability <±mg 1 1/6 0.7
Linearity <±mg 3 5 2
Corner load (test load [g]) mg 2 (1000) 3 (1000) 2 (500)
Min. initial weight* g 1.5 1.5 1.5
Sensitivity drift between +10 to +30°C ±ppm/K1 1 1.5
Typical stabilization time s < 1 < 1 < 1
Typical measurement time s < 1.5 < 1.5 < 1.5
External standard calibration value g 2000 (E2) 1000 (E2) 1000 (E2)
(min. accuracy class)
Display result
(depending on the set filter level) 0.1 – 0.4
Weighing pan size (W + D) mm 140 +140
Weighing chamber height mm 172
(draft shield DU)
Protection Protected against dust and water
* = Position according to OIML R76
