Sartorius Cubis Series User Manual

168 Cubis MSU User Manual
Specifications
Model-specific Data
Verified models with EC Type-Approval Certificate: Precision balances
Models MSU5203S-0CE MSU5203P-0CE MSU3203S-0CE MSU3203P-0CE
Accuracy class* kk kk
For verified models: EC Type-Approval Certificate D09-09-015, Type: MSX
Scale interval d* mg 1 1/2/5 1 1/10
Weighing capacity max* g 5200 1200/2400/5200 3.200 1010/3200
Calibration value e* mg 10 10 10 10
Min. load min* mg 100 100 100 100
Tare equalization range (subtractive) g < 100% from max. weighing capacity
Application range according to DIR* g 0.1 – 5200 0.1 – 5200 0.1 – 3200 0.1 – 3200
Min. initial weight** g 1.5 1.5 1.5 1.5
Typical stabilization time s < 1 < 1 < 1 < 1
Typical measurement time s < 2 < 2 < 2 < 1.5
External standard calibration value g 5000 5000 2000 2000 (E2)
(min. accuracy class)
Application range (temperature) With “isoCAL” function: +5 ... +40°C
Without “isoCAL” function: +15 ... +25 °C
Display result
(depending on the set filter level) 0.1 – 0.4
Weighing pan size (W + D) mm 140 +140
Weighing chamber height (draft shield DE) mm 172
Protection Protected against dust and water
Models MSU2203S-0CE MSU2203P-0CE MSU1203S-0CE
Accuracy class* kk k
For verified models: EC Type-Approval Certificate D09-09-015, Type: MSX
Scale interval d* mg 1 1/10 1
Weighing capacity max* g 2200 1010/2200 1200
Calibration value e* mg 10 10 10
Min. load min* mg 100 100 100
Tare equalization range (subtractive) g < 100% from max. weighing capacity
Application range according to DIR* g 0.1 – 2200 0.1 – 2200 0.1 – 1200
Min. initial weight** g 1.5 1.5 1.5
Typical stabilization time s < 1 < 1 < 1
Typical measurement time s < 1.5 < 1.5 < 1.5
External standard calibration value g 2000 (E2) 1000 (E2) 1000 (E2)
(min. accuracy class)
Application range (temperature) With “isoCAL” function: +5 ... +40°C
Without “isoCAL” function: +15 ... +25 °C
Display result
(depending on the set filter level) 0.1 – 0.4
Weighing pan size (W +D) mm 140 +140
Weighing chamber height (draft shield DE) mm 172
Protection Protected against dust and water
* DIR = Directive 90/384/EEC on non-automatic weighing instruments used within the European Economic Area
** = Typical min. initial weighing according to USP (Unites States Pharmacopeia), USP31-NF26

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
