Sartorius Cubis Series User Manual

Cubis MSU User Manual 169
Specifications
Model-specific Data
Verified models with EC Type-Approval Certificate: Precision balances
Models MSU623S-0CE MSU623P-0CE MSU323S-0CE
Accuracy class* mg KK K
For verified models: EG-Type-Approval Certificate D09-09-015, Type: MSX
Scale interval d* mg 1 1/2/5 1
Weighing capacity max* g 620 150/300/620 320
Calibration value e* mg 10 10 10
Min. load min* mg 20 20 20
Tare equalization range (subtractive) < 100% from max. weighing capacity
Application range according to DIR* g 0.02 – 620 0.02 – 620 0.02 – 320
Min. initial weight** g 1.5 1.5 1.5
Typical stabilization time s < 0.8 < 0.8 < 0.8
Typical measurement time s < 1 < 1 < 1
Application range (temperature) With “isoCAL” function: +5 to +40°C |
Without “isoCAL” function: +10 to +30°C
Display result
(depending on the set filter level) 0.1 – 0.4
Weighing pan size (W + D) mm 140 +140
Weighing chamber height mm 172
(draft shield DE)
Protection Protected against dust and water
Models MSU14202S- MSU14202P- MSU10202S- MSU8202S-
0CE 0CE 0CE 0CE
Accuracy class* kk k K
For verified models: EC Type-Approval Certificate D09-09-015, Type: MSX
Scale interval d* g 0.01 0.01/0.02/0.05 0.01 0.01
Weighing capacity max* g 14,200 3500/7000/14,200 10,200 8200
Calibration value e* g 0.1 0.1 0.1 0.1
Min. load min* g 1 1 1 0.5
Tare equalization range (subtractive) < 100% from max. weighing capacity
Application range according to DIR* g 1 – 14,200 1 – 14,200 1 – 10,200 0.5 – 8200
Min. initial weight** g 15 15 12 12
Typical stabilization time s < 1 < 1 < 1 < 1
Typical measurement time s < 1.5 < 1.5 < 1.5 < 1.5
Application range (temperature):
With “isoCAL” function +5 to +40°C +5 to +40°C +5 to +40°C +5 to +40°C
Without “isoCAL” function +15 to +25°C +15 to +25°C +15 to +25°C +10 to +30°C
Display result
(depending on the set filter level) 0.1 – 0.4
Weighing pan size (W + D) mm 206 +206
Protection Protected against dust and water
* DIR = Directive 90/384/EEC on non-automatic weighing instruments used within the European Economic Area
** = Typical min. initial weighing according to USP (Unites States Pharmacopeia), USP31-NF26

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
