Sartorius Cubis Series User Manual

Restore Factory Settings
You can reset all settings individually to the factory settings at any time.
t Use the cursor softkeys to navigate through the Device parameters sub-
menu to Restore factory settings.
t Mark any settings you wish to reset and select Next.
t Confirm the reset when prompted.
Motorized Draft Shield (Optional)
O
On balances equipped with a motorized draft shield [sometimes called a windshield
(WS)], the control unit has keys on the right and left sides which can be used
for the motor-driven opening and closing of the draft shield doors. You can config-
ure the functionality of these keys in the menu.
For example, you can configure the left key to open and close the right and upper
door (for users who are right-handed) and the right key to open and close the left
door (for users who are left-handed). The opening width (entirely or partially)
of the sliding panels can also be defined. You can configure these settings manually
on the draft shield itself (see “Learning Function” below).
t Check and correct all settings as required.
t To save the settings, select Save.
t Define the functions for the left and right keys:
Off, no function: The keys have no function.
Same function: Both keys have identical functions.
*Separate function: The left and right keys are configured with different
functions.
System Settings (Menu)
50 Cubis MSU User Manual

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
