Section 01 MAINTENANCE
Sub-Section 05 (STORAGE)
01-05-2
Propulsion System
Lubricant in impeller shaft reservoir should be
drained. Reservoir should be cleaned and refilled
with SEA-DOO synthetic 75W90 GL5 polyolester
oil. Refer to PROPULSION SYSTEM 08-02.
All Models Except XP and HX
Lubricate PTO flywheel at grease fitting with syn-
thetic grease (P/N 293 550 010).
1. Grease PTO flywheel
XP and HX Models
Lubricate mid bearing of drive system at seal car-
rier grease fitting with synthetic grease.
1. Grease fitting
Battery
For battery removal, cleaning and storage, refer to
ELECTRICAL 07-03.
Watercraft Cleaning
Clean the bilge with hot water and mild detergent
or with bilge cleaner. Rinse thoroughly. Lift front
end of watercraft to completely drain bilge. If any
repairs are needed to body or to the hull, touch up
paint and Gelcote
®
repair kit are available. Re-
place damaged labels/decals.
Wash the body with soap and water solution (only
use mild detergent). Rinse thoroughly with fresh
water. Remove marine organisms from the hull.
Apply a nonabrasive wax.
If the watercraft is to be stored outside, cover it
with an opaque tarpaulin to prevent sun rays and
grime from affecting the plastic components, wa-
tercraft finish as well as preventing dust accumu-
lation.
-
CAUTION
Use only SEA-DOO jet pump oil or equiva-
lent synthetic gear oil, otherwise component
life span could be reduced. Do not mix oil
brands or types.
-
CAUTION
Do not lubricate excessively. Immediately
stop when a slight movement is noticed on
rubber boot.
-
CAUTION
Never leave any clothing, tool or other ob-
jects near PTO flywheel and drive shaft.
F01I0BA
1
-
CAUTION
Never clean apparent fiberglass and plastic
parts with strong detergent, degreasing
agent, paint thinner, acetone, etc.
-
CAUTION
The watercraft must never be Ieft in water
for storage. Never leave the watercraft
stored in direct sunlight.
F05I09A
1
