Section 09 STEERING SYSTEM
Sub-Section 03 (GTS MODEL)
09-03-1
GTS MODEL 0
F02K0BS
5
Loctite
242
4
8
3.5 N•m
(30 lbf•in)
7
6
14 N•m
(10 lbf•ft)
1
29
26 N•m
(19 lbf•ft)
3
2
3.5 N•m
(30 lbf•in)
15 N•m
(11 lbf•ft)
Loctite
242
15
28
16
Anti-seize
lubricant
17
14
Loctite
242
15 N•m
(11 lbf•ft)
18
15 N•m
(11 lbf•ft)
Loctite
242
28
19
20
13
40 N•m
(30 lbf•ft)
Loctite
271
10
11
7 N•m
(63 lbf•in)
12
12
9
20 N•m
(15 lbf•ft)
22
7 N•m
(63 lbf•in)
21
23
24
10 N•m
(88 lbf•in)
27
26
25
2.5 N•m
(23 lbf•in)
2 N•m
(18 lbf•in)
22
30
6 N•m
(53 lbf•in)
30
