Section 09 STEERING SYSTEM
Sub-Section 03 (GTS MODEL)
09-03-5
1. One washer each side of arm
2. Torque nut to 2 N•m (18 lbf•in)
STEERING ALIGNMENT
For steering alignment procedure, refer to STEER-
ING SYSTEM 09-06.
-
CAUTION
Ensure the ball joint is parallel (± 5°) to the
nozzle arm.
