Section 01 MAINTENANCE
Sub-Section 05 (STORAGE)
01-05-4
TYPICAL
1. Hold hoses higher than tuned pipe
2. Insert funnel into engine water supply hose
NOTE:
If hoses are not attached higher than
tuned pipe, coolant will drain out.
XP and HX Models
Install a hose pincher to engine drain hose.
TYPICAL
1. Hose pincher
2. Drain hose
3. Magneto housing cover
Disconnect engine water supply hose and engine
water return hose.
TYPICAL
1. Engine water supply hose
2. Engine water return hose
Install temporarily one hose to engine water inlet
at cylinder head.
Insert a funnel into hose and pour about 1 liter (1 qt)
of antifreeze mixed with water in engine.
Remove temporary hose and reconnect engine
water supply hose and engine water return hose.
Remove hose pincher.
All Models
Most of the antifreeze will drain out when remov-
ing hose pinchers. Use a container to recover it.
Dispose antifreeze as per your local laws and reg-
ulations.
NOTE:
Although antifreeze will mainly drain out,
the antifreeze has flowed to mix with water that
was possibly trapped in cooling system cavities
and thus preventing freezing problems.
NOTE:
For pre-season preparation, drain anti-
freeze from cooling system prior to launching
boat in water as explained above.
1
F00E03A
2
F05E02A
1 32
F05E03A
1
2
