Section 12 TECHNICAL DATA
Sub-Section 01 (SP AND SPX MODELS)
12-01-5
TIGHTENING TORQUES SP (5879) SPX (5834/5661)
ENGINE
Exhaust manifold screw 24 N•m (17 lbf•ft) (4)
40 N•m (30lbf•ft) (3) (4)
Magneto flywheel nut 145 N•m (107 lbf•ft) (1)
105 N•m (77 lbf•ft) (1)
Flywheel (PTO side) 110 N•m
(81 lbf•ft) (5)
Crankcase screws
M8 24 N•m
(17 lbf•ft) (3) (4)
M10 40 N•m
(30 lbf•ft) (3) (4)
Crankcase/engine support nuts 35 N•m
(26 lbf•ft) (1)
Engine mount/hull 25 N•m
(18 lbf•ft) (1)
Cylinder head screws 24 N•m
(17 lbf•ft) (1) (4)
Crankcase/cylinder screws
24 N•m (17 lbf•ft) (1) (4)
40 N•m (30 lbf•ft) (3) (4)
Tuned pipe flange screws/nut
25 N•m (18 lbf•ft) (1)
40 N•m (30 lbf•ft) (1)
Tuned pipe fixation screws 25 N•m
(18 lbf•ft) (1)
Flame arrester screws 10 N•m
(88 lbf•
in
)(1)
Magneto housing cover screws 9 N•m
(80 lbf•
in
)(5)
Starter mounting screws 22 N•m
(16 lbf•ft) (1)
Starter lock nuts 7 N•m
(62 lbf•
in
)
Spark plugs 24 N•m
(17 lbf•ft) (5)
JET PUMP
Impeller 70 N•m
(52 lbf•ft) (2)
Pump/hull nuts 33 N•m
(24 lbf•ft) (1)
Venturi/pump housing screws 21 N•m
(16 lbf•ft) (1)
VTS ring screws Not applicable
14 N•m (10 lbf•ft) (1)
Pump housing cover screws 4 N•m
(35 lbf•
in
)(1)
Inlet grate screws 8 N•m
(71 lbf•
in
)(1)
Riding plate screws 10 N•m (88 lbf•
in
)(1)
STEERING
Cable retaining block bolts 6 N•m (53 lbf•
in
)
Steering cable/stem arm bolt 3 N•m (26 lbf•
in
)
Steering stem arm bolts 6 N•m (53 lbf•
in
)
Handlebar clamp bolts 26 N•m (19 lbf•ft)
Steering cable ball joint (nozzle) 2 N•m (18 lbf•
in
) 7 N•m (62 lbf•
in
)
Front support bolts 15 N•m (11 lbf•ft)
Rear support/cable bracket bolts 15 N•m (11 lbf•ft)
ADDITIONAL INFORMATION: apply where indicated; (1) Loctite 242 (blue)
(2) Loctite 271 (red)
(3) Loctite 515
(4) Synthetic grease
(5) Anti-seize lubricant
;
WARNING: Correct torques and use of Loctite must be strictly followed.
