HF Series Generators
Configuration
CF-1018R3
25
3.2.1.3 CONFIGURATION FOR TWO TUBES WITH DIFFERENT STARTING VOLTAGE AND
CAPACITOR OR ONE TUBE WITH STARTING VOLTA GE AT 330 VAC
For Generators equipped with a LF-RAC module for two X-ray Tubes, with
possible selection of voltage and capacitor jumpers on the LF-RAC Board, set
jumpers according to the respective X-ray Tube(s) as indicated below.
TWO TUBES WITH STARTING VOLTAGE AT 220 VAC AND 330 VAC
OR ONE TUBE WITH STARTING VOLTAGE AT 330 VAC
(A “Kit of 330 VAC” is required with this configuration).
TUBE-1 TUBE-2
V
O
L
T
A
G
E
220 VAC TB2-T1 with TB1-5 or TB1 -6 TB2-T2 with TB1-5 or TB1 -6
V
OLT
A
GE
330 VAC TB2-T1 with TB1-8 or TB1 -9 TB2-T2 with TB1-8 or TB1--9
C
A
P
A
C
I
T
O
R
30 μF
TB3-T1 with TB1-12 or TB1-13 TB3-T2 with TB1-12 or TB1-13
C
A
P
A
CITOR
15 μF
TB3-T1 with TB1-15 or TB1-16 TB3-T2 with TB1-15 or TB1-16
10C5--2
30uF
10R4--2
1 Mohm, 2w
10LF2
2
1
4
3
10K1
2
1
230 VAC RTR
60 VAC RTR
(S1,2--D2)
30uF
F1
T6A
8
9
5
4
6
Tube 1
11 12
13
14 15
16
10
1
2
3
K2--1
KCT
K2--3
KCT
TB1
TB1
K1--1
KACC
T1
TB2
Tube 2
T2
TB2
Tube 1
T2
TB3
T1
TB3
Tube 2
LF--RAC BOARD
47
2w
100 nF
1KV
10A1
T1/T2 COMM
(to 10TS2)
0VACRTR
2
3
1
10J8
10RC1
7
330V
220V
0V
10T3
10C5--1
15uF
10R4--1
1 Mohm, 2w
NOTE.-- 10T3, 10C5--1 and
10R4--1 for 330 VAC Stator
