HF Series Generators
Configuration
CF-1018R3
30
Dip Switch 3000SW2 on the HT Controller Board is used to program:
• Rad Filament Setting Time. This value is programmable from 0.8 to 2.7
seconds. It can be initially set as the same value assigned for the Rotor
Acceleration Time (refer to technical information of the X-ray Tube)
Sometimes, if it is required to increase the Rad Filament Setting Time to
the next value, configure the respective switches again. This adjustment
avoids Error-12.
• Fluoro Rotor Hold-over Time and Fluoro Filament Hold-over Time.This
value can be programmed to run for 1 minute or not at all, after releasing
the Fluoro Pedal.
The Rad Filament Setting Time is factory set to 1.8 seconds. The
Fluoro Filament Hold-over Time is factory set to 1 minute. Maintain
this value when it is unknown or not provided with the X-ray Tube
documentation.
1. Turn the Generator OFF and note current settings of the dip switch
3000SW2 on the HT Controller Board.
Configuration of these times are only allowed when dip switch
3000SW2-1 is in “Closed” (On) position after power the Generator
OFF and back ON again.
2. Set dip switches 3000SW2-1 and 3000SW2-2 as indicated below, in
order to enable the selection of times with the High Speed Starter. Dip
switch3000SW2-1 has t o be switched ONLY with the Generator
powered OFF.
3000SW2-1 (selection enable) 3000SW2-2 (High Speed Starter)
ON ON
Note .
Note .
