HF Series Generators
Pre-Installation
PI-1005R3
9
Illustration 2-1 (cont.)
Consoles
400
PC UNIT
400
PC INTERFACE BOX
45
124
1010
123
1023
PEDESTAL (optional)
R&F CONSOLE
RAD CONSOLE
PEDESTAL (optional)
TOUCH SCREEN CONSOLE
Cable Access
Mounting Holes ø8
Cable Access
Mounting Holes ø8
Cable Access
FOR PC
