HF Series Generators
Pre-Installation
PI-1005R3
10
Illustration 2-1 (cont.)
Consoles
TOUCH SCREEN CONSOLES (TPC)
THESE CONSOLES CAN BE MOUNTED ON A TABLE SUPPORT, WALL SUPPORT OR PEDESTAL
RAD CONSOLES -- GRAPHIC DISPLAY
PEDESTAL
TABLE S UPPORT
WALL SUPPORT
