Sedecal SHF-310 - Page 158

HF Series Generators
LV-DRAC
DR-1004R8
2
3243SW3-x FUNCTION
1 LOW SPEED ROTATION BRAKE
2 NOT USED*
3 SPOT FILM HIGH SPEED START
4 NOT USED*
5
ON = WHEN THE TUBE CONFIGURED AS TUBE-1
IS LISTED ON TUBE TABLE-1
5
OFF = WHEN THE TUBE CONFIGURED AS TUBE-1
IS LISTED ON TUBE TABLE-2
6
7
NOT USED*
8
* Note: Set switches not used in “ON” position.
3243SW4-x FUNCTION
1
2
S
P
O
T
F
I
L
M
H
O
L
D
T
I
M
E
3
SPOT FILM HOLD TIME
4
5
ON = WHEN THE TUBE CONFIGURED AS TUBE-2
IS LISTED ON TUBE TABLE-1
5
OFF = WHEN THE TUBE CONFIGURED AS TUBE-2
IS LISTED ON TUBE TABLE-2
6
ON = SELF RUNNING ENABLED (Refer to section 1.2)
6
OFF = SELF RUNNING DISABLED (Refer to section 1.2)
7 PROTECTIONS -- ERRORS
8 DC BRAKE
* Note: Set switches not used in “ON” position.
Set dip switches in accordance with the following tables.
Note .
