HF Series Generators
LV-DRAC
DR-1004R8
3
TUBE SELECTION -- TUBE TABLE-1
(Switch 3243SW3-5 = ON for Tube-1 ) (Switch 3243SW4-5 = ON for Tube-2)
P
T
U
B
E
F
A
M
I
L
Y
3243SW1-x (TUBE-1) 3243SW2-x (TUBE-2)
Pos
T
U
B
E
F
A
M
I
L
Y
(Stator - ∅ Anode)
4 5 6 7 8 4 5 6 7 8
0 GE MAXIRAY 75 ON ON ON ON ON ON ON ON ON ON
1 GE MAXIRAY 100 OFF ON ON ON ON OFF ON ON ON ON
2 VARIAN G-1582 ON OFF ON ON ON ON OFF ON ON ON
3
EUREKA RAD-XX (with Insert 3”)
VARIAN RAD-XX (with Insert 3”) / A132
OFF OFF ON ON ON OFF OFF ON ON ON
4
EUREKA RAD-XX (with Insert 4”)
VARIAN RAD-XX (with Insert 4”) / A256 / A282 / A292
TOSHIBA 7254X / 7255X
ON ON OFF ON ON ON ON OFF ON ON
5 CGR STATORIX M50 OFF ON OFF ON ON OFF ON OFF ON ON
6
SIEMENS 100 L BIANGULIX
SIEMENS 100 L OPTILIX
ON OFF OFF ON ON ON OFF OFF ON ON
7 PHILIPS SUPEROTALIX OFF OFF OFF ON ON OFF OFF OFF ON ON
8 DUNLEE PX-1302 ON ON ON OFF ON ON ON ON OFF ON
9 CGR STATORIX 260 / RSN 742 OFF ON ON OFF ON OFF ON ON OFF ON
10
CGR STATORIX 550 / RSN 722 / MSN 722
IAE RTC 600
ON OFF ON OFF ON ON OFF ON OFF ON
11 SIEMENS 100 G OFF OFF ON OFF ON OFF OFF ON OFF ON
12 SIEMENS RH 150/100 ON ON OFF OFF ON ON ON OFF OFF ON
13 COMET DO-10 (with Insert 4”) OFF ON OFF OFF ON OFF ON OFF OFF ON
14 COMET DO-9 (with Insert 4”) ON OFF OFF OFF ON ON OFF OFF OFF ON
15 CGR STATORIX 240 OFF OFF OFF OFF ON OFF OFF OFF OFF ON
16 PICKER PX-307 ON ON ON ON OFF ON ON ON ON OFF
17 HANGZHOU XD-52-30, 50/150 OFF ON ON ON OFF OFF ON ON ON OFF
18 DUNLEE PX-1312 ON OFF ON ON OFF ON OFF ON ON OFF
19 DUNLEE PX-1456 / PX-1436 / PX-1400 (Stator Q) OFF OFF ON ON OFF OFF OFF ON ON OFF
20 COMET DX-1000 ON ON OFF ON OFF ON ON OFF ON OFF
21 COMET DX-81 / COMET XSTAR-14 OFF ON OFF ON OFF OFF ON OFF ON OFF
22 PHILIPS ROTALIX 350/351 ON OFF OFF ON OFF ON OFF OFF ON OFF
23 COMET MOS-50 (MAMMO) OFF OFF OFF ON OFF OFF OFF OFF ON OFF
24 VARIAN B110 / B112 / B115 ON ON ON OFF OFF ON ON ON OFF OFF
25 VARIAN B160 / B165 OFF ON ON OFF OFF OFF ON ON OFF OFF
26 TOSHIBA E7252 (stator XS-AL) ON OFF ON OFF OFF ON OFF ON OFF OFF
27 COMET DX 700 HS OFF OFF ON OFF OFF OFF OFF ON OFF OFF
28 VARIAN B130 + A192 / A196 / A197 ON ON OFF OFF OFF ON ON OFF OFF OFF
29 VARIAN G 1592 OFF ON OFF OFF OFF OFF ON OFF OFF OFF
30 PICKER PX400P + PX457P ON OFF OFF OFF OFF ON OFF OFF OFF OFF
31 JUGORENDGEN RX 150/30--50 OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF
