HF Series Generators
LV-DRAC
DR-1004R8
4
TUBE SELECTION -- TUBE TABLE-2
(Switch 3243SW3-5 = OFF for Tube-1 ) (Switch 3243SW4-5 = OFF for Tube-2)
P
o
s
TUBE F
A
MIL
Y
3243SW1-x (TUBE-1) 3243SW2-x (TUBE-2)
Pos
T
U
B
E
F
A
M
I
L
Y
(Stator - ∅ Anode)
4 5 6 7 8 4 5 6 7 8
0 VARIAN GS-20711 + Housing B220H (Stator R) ON ON ON ON ON ON ON ON ON ON
1 SIEMENS 100 L--W OFF ON ON ON ON OFF ON ON ON ON
2 SIEMENS SV 125/15/82 ON OFF ON ON ON ON OFF ON ON ON
3 IAE RTM90+ Housing C55 OFF OFF ON ON ON OFF OFF ON ON ON
4
IAE RTM101HS + Housing C100
IAE RTM102HS + Housing C100
ON ON OFF ON ON ON ON OFF ON ON
5 DUNLEE DA 1036 -- DU 404 OFF ON OFF ON ON OFF ON OFF ON ON
6 DUNLEE DA 1094 -- DU 694 ON OFF OFF ON ON ON OFF OFF ON ON
7
DUNLEE DR 1825 (High Impedance Stator)
DUNLEE DR 1817 (High Impedance Stator)
OFF OFF OFF ON ON OFF OFF OFF ON ON
8 CGR STATORIX 240, MSN 740, MSN 742 ON ON ON OFF ON ON ON ON OFF ON
9 IAE RTC 700 HS + Housing C52 SUPER OFF ON ON OFF ON OFF ON ON OFF ON
10 VARIAN GS 30711 ON OFF ON OFF ON ON OFF ON OFF ON
11 VARIAN BI 130+G292 / G294 OFF OFF ON OFF ON OFF OFF ON OFF ON
12 IAE RTM102HS + Housing C52S ON ON OFF OFF ON ON ON OFF OFF ON
13 IAE RTC1000HS + Housing C52S OFF ON OFF OFF ON OFF ON OFF OFF ON
14 TOSHIBA ROTANODE E7100X ON OFF OFF OFF ON ON OFF OFF OFF ON
15 DUNLEE DA 1083 / PX 1483 -- DU 404 / DA 10 (Stator C) OFF OFF OFF OFF ON OFF OFF OFF OFF ON
16 VARIAN A277 / A278 + Housing B150H (Stator R) ON ON ON ON OFF ON ON ON ON OFF
17 VARIAN G1092 + Housing B160 / B165 (Stator R) OFF ON ON ON OFF OFF ON ON ON OFF
18 DUNLEE PX1473Q -- DU 604 ON OFF ON ON OFF ON OFF ON ON OFF
19 TOSHIBA E7260DX OFF OFF ON ON OFF OFF OFF ON ON OFF
20 VARIAN HE100 + Housing B180 / B185 (Stator R) ON ON OFF ON OFF ON ON OFF ON OFF
21 IAE RTC 137 + Housing CT 180 OFF ON OFF ON OFF OFF ON OFF ON OFF
22 VARIAN A102 + Housing B100 ON OFF OFF ON OFF ON OFF OFF ON OFF
23
IAE X40 + Housing C352 (only Low Speed)
IAE RTM78HS + Housing C352
OFF OFF OFF ON OFF OFF OFF OFF ON OFF
24 ON ON ON OFF OFF ON ON ON OFF OFF
25 TOSHIBA ROTANODE E7867X / E7869X OFF ON ON OFF OFF OFF ON ON OFF OFF
26 TOSHIBA ROTANODE E7240X ON OFF ON OFF OFF ON OFF ON OFF OFF
27 OFF OFF ON OFF OFF OFF OFF ON OFF OFF
28 ON ON OFF OFF OFF ON ON OFF OFF OFF
29 TOSHIBA E7252X (Stator XS--R) OFF ON OFF OFF OFF OFF ON OFF OFF OFF
30 ON OFF OFF OFF OFF ON OFF OFF OFF OFF
31 OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF
