Sedecal SHF-310 - Page 162

HF Series Generators
LV-DRAC
DR-1004R8
6
SPOT FILM HOLD TIME
SPOT FILM
3243SW4-x
S
P
O
T
F
I
L
M
HOLD TIME
1 2 3 4
0 ON ON ON ON
5 OFF ON ON ON
10 ON OFF ON ON
S
E
C
O
N
D
S
15 OFF OFF ON ON
SECONDS
20 ON ON OFF ON
30 OFF ON OFF ON
45 ON OFF OFF ON
60 OFF OFF OFF ON
2 ON ON ON OFF
5 OFF ON ON OFF
10 ON OFF ON OFF
M
I
N
U
T
E
S
15 OFF OFF ON OFF
MINUTES
20 ON ON OFF OFF
25 OFF ON OFF OFF
30 ON OFF OFF OFF
40 OFF OFF OFF OFF
SPOT FILM HIGH SPEED START
SPOT FILM START MODE 3243SW3-3
SPOT FILM ALWAYS STARTS IN HIGH SPEED (10000 RPM) ON
SPOT FILM STARTS AT REQUIRED SPEED OFF
