HF Series Generators
T roubleshooting
TR-1005R4
29
ERROR CODE LIST
ERROR CODE DESCRIPTION
E66 DRAC -- EXCESSIVE CURRENT IN MAIN WINDING RUNNING AT 3300 RPM.
E67 DRAC -- EXCESSIVE CURRENT IN AUXILIAR WINDING RUNNING AT 3300 RPM.
E68 DRAC -- INSUFFICIENT CURRENT IN AUXILIAR WINDING RUNNING AT 3300 RPM.
E69 DRAC -- INSUFFICIENT CURRENT IN MAIN WINDING RUNNING AT 3300 RPM.
E70 DRAC -- EXCESSIVE CURRENT IN MAIN WINDING RUNNING AT 10000 RPM.
E71 DRAC -- EXCESSIVE CURRENT IN AUXILIAR WINDING RUNNING AT 10000 RPM.
E72 DRAC -- INSUFFICIENT CURRENT IN AUXILIAR WINDING RUNNING AT 10000 RPM.
E73 DRAC -- INSUFFICIENT CURRENT IN MAIN WINDING RUNNING AT 10000 RPM.
E74 DRAC -- EXCESSIVE CURRENT IN MAIN WINDING BRAKING AT 3300 RPM.
E75 DRAC -- EXCESSIVE CURRENT IN AUXILIAR WINDING BRAKING AT 3300 RPM.
E76 DRAC -- INSUFFICIENT CURRENT IN AUXILIAR WINDING BRAKING AT 3300 RPM.
E77 DRAC -- INSUFFICIENT CURRENT IN MAIN WINDING BRAKING AT 3300 RPM.
E78 DRAC -- EXCESSIVE CURRENT IN MAIN WINDING BRAKING AT 10000 RPM.
E79 DRAC -- EXCESSIVE CURRENT IN AUXILIAR WINDING BRAKING AT 10000 RPM.
E80 DRAC -- INSUFFICIENT CURRENT IN AUXILIAR WINDING BRAKING AT 10000 RPM.
E81 DRAC -- INSUFFICIENT CURRENT IN MAIN WINDING BRAKING AT 10000 RPM.
E82 DRAC -- WRONG X-RAY TUBE SELECTION.
E83 DRAC -- EXCESSIVE CURRENT IN DC BRAKE.
E84 DRAC -- INCORRECT TUBE SELECTION SIGNAL.
E85 DRAC -- INCORRECT TUBE SELECTION SIGNAL.
E86 DRAC -- INCORRECT TUBE SELECTION SIGNAL.
E87 DRAC -- INSUFFICIENT CURRENT IN COMMON WIRE DURING ACCELERATION UP TO 3300 RPM
E88 DRAC -- INSUFFICIENT CURRENT IN COMMON WIRE RUNNING AT 3300 RPM
E89 DRAC -- INSUFFICIENT CURRENT IN COMMON WIRE DURING ACCELERATION UP TO 10000 RPM
E90 DRAC -- INSUFFICIENT CURRENT IN COMMON WIRE RUNNING AT 10000 RPM
E91 DRAC -- INCORRECT MEASURE AT IPRINC (CH2)
E92 DRAC -- INCORRECT MEASURE AT IAUX (CH3)
E93 DRAC -- INCORRECT MEASURE AT ICOM (CH4)
E95 RAPID TERMINATION
E96 CAPACITOR ASSISTED GENERATOR -- VOLTAGE MISSING
E97 CAPACIT OR ASSISTED GENERATOR -- VOLTAGE IN CAPACITORS NOT BALANCED
E98
DIP SWITCH 3024SW2-3 IN A TP CONSOLE CPU BOARD SET FOR CONFIGURATION AND CALIBRA TION
MODE ACTIVE (SERVICE MODE).
