HF Series Generators
T roubleshooting
TR-1005R4
30
ERRORCODE: “------------”
DESCRIPTION : System failure.
ERROR TYPE : Fatal error. Generator must be switched off.
APPLICABLE TO : All Generators
APPEARS WHEN : This indication may appear at any time together with another Error Code on the Console.
INFORMATION / SYMPTOM : This Error Code needs to turn OFF/ON the Generator to be fixed.
ACTIONS
1. Turn the Generator OFF, wait a few seconds and turn it ON.
ERROR CODE : E01
DESCRIPTION : Failure in power up routine.
No communication between HT Controller Board and ATP Console CPU Board.
ERROR TYPE : Fatal error. Generator can not continue with power up.
APPLICABLE TO : All Generators
APPEARS WHEN : Only during initialization phase. If it appears during normal functioning of equipment, it means that
a problem has caused a power off in the Console.
INFORMATION / SYMPTOM : This Error Code needs to turn OFF/ON the Generator to be fixed.
It has not been possible to establish a correct communication between ATP Console and HT
Controller Boards during power ON and the Generator is not able to make Exposures.
If Led 1 of the HT Controller remains lit, it means that HT Controller has not been started.
POSIBLE CAUSES
The Console has been suddenly switched OFF by operator or by a shut-off on the line.
The Microprocessor U5 on the HT Controller Board has not started-up.
The communication between ATP Console Board and HT Controller Board is not reliable.
ACTIONS
1. Check DC supplies.
2. Check the software version in case of update or change the A TP Console or HT Controller
Boards. Check and replace if necessary U5 in HT Controller and U24 on ATP Console Board.
3. Check continuity between terminals 2, 3, 5 and 6 on J3 of ATP Console Board and P1-4, P1-11,
P1-15, P1-10 of HT Controller Board. Check with special care connector 6J3 of the Generator.
4. Switch OFF, wait a few seconds and switch ON again to reset the Error Code.
5. If not fixed after previous steps, check Led DS1 in HT Controller Board when powering the
equipment, if it has not turned of f, replace HT Controller Board.
6. If Led DS1 is off, check with an oscilloscope the following signals: HT-C CLK, HT-C DA T,
C-HT CLK and C-HT DAT in order to find a possible defective component at any of both Boards
(HT Controller and ATP Console). Replace the Board where the defective component is found.
