HF Series Generators
T roubleshooting
TR-1005R4
64
ERROR CODE : E37 -- TUBE OVERLOAD
DESCRIPTION : Tube Overload.
ERROR TYPE : Informative without acoustic alarm. Does not allow Exposition.
APPLICABLE TO : All Generators.
APPEARS WHEN : After “Exp” due to Tube overheating. After changing radiographic parameters. In some Consoles
this error may not appear as they are provide with an automatic blocking that disable parameters
above tube capacity .
INFORMATION / SYMPTOM : Indicated with warning “Tube Overload” in Consoles with written indicators. For the rest of
Consoles E37 appears in display . Exposures are not allowed.
POSIBLE CAUSES
1. Parameters selected for a new exposition are above tube capacity . (Heat Units or Rating).
2. Capacity Line frequency is wrong. (see SW1.1 at Console) or Tube selected in extended position
E02 or E18 is not correct.
ACTIONS
1. Wait for Tube to cool and Heat Units available increase or modify Exposition parameters.
2. If Heat Units of tube are 100% and E37 or “Tube Overload” warning appear: Check 3024SW1.1
in ATP Console. See Configuration Chapter in Service Manual and Test Switches or verify the
X-Ray T ype Selection: E02 for Tube 1 and E18 for Tube 2 in Configuration Chapter of Service
Manual.
ERROR CODE : E41
DESCRIPTION : Dosimeter failure. Communication failure between Tube-1 Dosimeter and Generator.
ERROR TYPE : Indicative.
APPLICABLE TO : All Generators with Dosimeter.
APPEARS WHEN : Communication error starting the measuring for Tube-1.
INFORMATION / SYMPTOM : Communication error 18 seconds after Tube-1 selection.
POSIBLE CAUSES
Wrong Physical connection between Dosimeter and System for Tube-1.
ACTIONS
1. Check cable connections between Dosimeter and System.
2. Turn Off and On the Generator to reset the Radiation Measuring System.
