HF Series Generators
Troubleshooting
TR-1005R4
111
5.4 LVDC POWER SUPPLY
POTENTIOMETERS
POTENTIOMETER RATING DESCRIPTION
R12 2K, 1w +5 VDC ADJUST
R25 2K, 1w -- 12 VDC ADJUST
R26 2K, 1w +12 VDC ADJUST
5.5 CHARGE/DISCHARGE MONITOR BOARD
LEDs
LED COLOR DESCRIPTION
DS1 GREEN
CHARGE INDICATOR OF THE HT INVERTER CAPACITORS:
LED OFF: NO CHARGE
LED ON: CHARGE ACCORDING TO BRIGHTNESS
5.6 LOCKS BOARD
FUSES
FUSE RATING NOMINAL DESCRIPTION
F14 10 A, 250 V, S.B. 24 VAC LOCKS/LAMP
F15 10 A, 250 V, S.B. 24 VAC LOCKS/LAMP
