HF Series Generators
Troubleshooting
TR-1005R4
110
LEDs
LED COLOR DESCRIPTION
DS1 GREEN GENERATOR POWER ON INDICATOR
POTENTIOMETERS
POTENTIOMETER RATING DESCRIPTION
R29 5K, 1/2w ION CHAMBER POSITIVE HIGH VOLTAGE ADJUST
RELAYS
RELAY RATING DESCRIPTION
K1 -- POWER ”ON” +6VDC COIL, 7A/250V CONTACT, DPDT GENERATOR POWER ON
K2 -- BUCKY 1 +24VDC COIL, 7A/250V CONTACT, DPDT BUCKY 1 DRIVE
K3 -- BUCKY 2 +24VDC COIL, 7A/250V CONTACT, DPDT BUCKY 2 DRIVE
K4 -- BUCKY MOTION +24VDC COIL, 7A/250V CONTACT, DPDT BUCKY EXPOSURE ENABLE
K5 -- SOL DR +24VDC COIL, 7A/250V CONTACT, DPDT HV TRANSFORMER SOLENOID DRIVE
K6 -- TUBE 1 +24VDC COIL, 7A/250V CONTACT, DPDT TUBE FILAMENT PREHEAT SELECTION
K7 -- SM SPOT (RAD) +24VDC COIL, 7A/250V CONTACT, DPDT SMALL/LARGE FILAMENT SELECTION
K8 +24VDC COIL, 7A/250V CONTACT, DPDT DELAYED +24VDC AND +5VDC
K9 +24VDC COIL, 7A/250V CONTACT, DPDT BUS DC DISCHARGE WITH POWER OFF
K10 +24VDC COIL, 7A/250V CONTACT, DPDT ROOM LIGHT CONTACT
K11 PhotoMOS Relay, SPST FILAMENT ACKNOWLEDGEMENT
