HF Series Generators
Troubleshooting
TR-1005R4
120
5.13 LV-DRAC (HIGH SPEED STARTER)
5.13.1 DELAYED SWITCH-OFF BOARD
RELAYS
RELAY RATING DESCRIPTION
K1 +12VDC COIL, 1A CONTACT, SPST SWITCH-OFF DELAYED
K2 +12VDC COIL, 1A CONTACT, SPST SWITCH-OFF MAINTAINED
5.13.2 CONTROL DRAC BOARD
JUMPERS / SWITCHES
JUMPER / SWITCH DESCRIPTION
SW1 SYSTEM CONFIGURATION 8 POSITIONS DIP SWITCH
SW2 SYSTEM CONFIGURATION 8 POSITIONS DIP SWITCH
SW3 SYSTEM CONFIGURATION 8 POSITIONS DIP SWITCH
SW4 SYSTEM CONFIGURATION 8 POSITIONS DIP SWITCH
LEDs
LED COLOR DESCRIPTION
DL1 RED ERROR STATUS
DL2 (flashing) YELLOW CODE STATUS
DL3 (ON) YELLOW READY
DL4 (ON) YELLOW TUBE 1 SELECTED
DL5 (ON) YELLOW TUBE 2 SELECTED
DL6 (ON) YELLOW DC BRAKE
DL7 (ON) YELLOW BUS DC+
DL8 (ON) YELLOW BUS DC--
RELAYS
RELAY RATING DESCRIPTION
RL2 +12VDC COIL, 1A CONTACT, SPST READY
