HF Series Generators
Troubleshooting
TR-1005R4
121
5.13.3 INTERFACE DRAC--HF BOARD
LEDs
LED COLOR DESCRIPTION
DS1 GREEN BUS DC
FUSES
FUSE RATING NOMINAL DESCRIPTION
F1 0.5 A, 250 V, S.B. 220 VAC 220 SUPPLY
F2 0.5 A, 250 V, S.B. 220 VAC 220 SUPPLY
F3 15 A, 250 V, S.B. 220 VAC BUS DC--
F4 15 A, 250 V, S.B. 220 VAC BUS DC+
5.13.4 DRAC MISCELLANEOUS
RELAYS
RELAY RATING DESCRIPTION
K1 RELAY +24VDC COIL, 7A/250V CONTACT, 3 Fom C TUBE 1 SELECTED
K3 CONTACTOR +24VDC COIL, 15A/250V CONTACT, 3NA DC BRAKE
KT1 CONTACTOR +24VDC COIL, 15A/250V CONTACT, 3NA TUBE 1 SELECTED
