5.14 CABINET MISCELLANEOUS FOR LINE POWERED GENERATORS
FUSES
FUSE RATING NOMINAL DESCRIPTION
F2 1.5 A, 250 V, S.B. 220 VAC 220 VAC SUPPLY LOCATION -- RECTIFIER PANEL
F3 50 A, 600 V, S.B. LINE LINE -- L1 LOCATION -- CABINET FRAME
F4 50 A, 600 V, S.B. LINE LINE -- L2 ” ”
F5 50 A, 600 V, S.B. LINE LINE -- L3 ” ”
F6 3 A, 250 V, S.B. 19 VAC +24V SUPPLY LOCATION -- RECTIFIER PANEL
F7 3 A, 250 V, S.B. 10.4 VAC +12V UNR SUPPLY ” ”
F8 3 A, 250 V, S.B. 115 VAC 115 VAC SUPPLY ” ”
F9 0.4 A, 250 V, S.B. 220 VAC 220 VAC LVDC LOCATION - - FRONT PANEL
F12 10 A, 250 V, S.B. LINE INPUT TRANSFORMER LOCATION -- BACK PANEL
F13 10 A, 250 V, S.B. LINE INPUT TRANSFORMER ” ”
F14 10 A, 250 V, S.B. LINE LINE OUTPUT -- U LOCATION -- CABINET FRAME
F15 10 A, 250 V, S.B. LINE LINE OUTPUT -- V ” ”
F16 10 A, 250 V, S.B. LINE LINE OUTPUT -- W ” ”
NOTE.-- FUSES F14, F15, F16 ARE ONLY INSTALLED IN VERTICAL GENERATOR CABINET, NEVER IN COMPACT MODEL.
RELAYS
RELAY RATING DESCRIPTION
K1 SOLID STATE RELAY +24VDC INPUT, 10A/250V OUTPUT ROTOR START RELAY
K3 110VAC COIL, 12A/250V CONTACT, 4PDT POWER INPUT RELAY
K5 CONTACTOR +24VDC COIL, 50A/600V CONTACT, 3 POLE LINE CONTACTOR
K6 CONTACTOR +24VDC COIL, 50A/600V CONTACT, 3 POLE CHARGE CONTACTOR
