Sedecal SHF-310 - Page 423

HF Series Generators
Renewal Parts
RP-1024R0
6
LOCKS AND ADAPT ATIONS PANEL (MOD. 12) / HV TRANSFORMER
Item Designation Qty FRU Rep Mfg. Ref. Remarks
LOCKS AND ADAPTATIONS PANEL (MOD. 12)
32 PCB, Locks 1 1 N A3214--01
33 PCB, AEC Cabinet A daptation -- 4 Ion Chambers 1 2 Y A3263--03 Used for 4 Ion Chambers
34 Fuses F14, F15 (10 A, 250V) SB SeeFuseKit
HV TRANSFORMER
35 HV Transformer (150 kV ) 1 Tube, 400 VAC 1 1 Y A6097--07
35 HV Transformer (150 kV ) 1 Tubes, 480 VAC 1 1 Y A6097--08
32
33
34
35
