9-18
Shared settings
9
[NUMERIC CALC] (TYPE00)
1CALC. RESULT AN00(0~15)
2OBJECT TYPE NO INDV-MEAS-RSLT[N] FINAL-RESULT[AN]
NUM-CALC[NC] CNST[C]
3FORMULA MEAS0(0~3) CMR1(1~2) N00(0~15)
+-＊ / ←→ DEL. END
4UPPER&LOWER LIMIT
＋
00000000.0~
＋
00000000.0
5OUTPUT NO Y0(0~7) C000(0~107)
6RUN A TEST(SET KEY)
7UPPER MENU
N00
N01
N02
N03
[N]
01N00+02N00+3N01 Y1
+00009800.0~ +00010000.0
＋
00009800.0 OK
[Results of the calculations
for measurement 0, camera
1: N00] + [Results of the
calculations for
measurement 0, camera 2:
N00] + [Results of the
calculations for
measurement 3: N01]
Example:
On the MAIN OPS MENU, move the cursor to SET-SCRN and press the SET key.
-On the [SYSTEM SETUP] menu, move the cursor to 2OBJECT TYPE COND (conditions of
object type) and press the SET key.
-On the [OBJECT TYPE COND] menu, move the cursor to eFINAL CALC RESULT (final
numeric calculation) and press SET key.
· The display areas on the screen are in the same places as those for item (1) individual
numerical calculations for each measuring program.
Numerical calculation
1 CALC.RESULT
2 OBJECT TYPE
3 FORMULA
(registaration number)
4 UPPER&LOWER LIMIT
5 OUTPUT
6 RUN A TEST
7 UPPER MENU
Setting details
The location where the rule 4 calculation result of the specified output data is
stored may be set from 00 to 15.
Select the type of data being calculated.
A number of style settings are used.
The first line will change according to the selection made in item 2.
Note: Please use a smaller number for entering numbers at AN (00 to 15)
than that 1 CALC. RESULT (calculations results) AN (00 to 15).
Enter the upper and lower limits for making a decision.
Setting the output of the calculation results.
Pressing the SET key will record the setting details as well as run a test.
This will return you to the [OBJECT TYPE COND] (conditions of object type)
Selection of 2
Calculation results for
measurements [N]
Final calculation results [AN]
Numerical calculations [NC]
Constant [C]
The first line of the display
Measurement 0 (0 to 3) camera 1 (1 to 2)
N00 (0 to 15)
AN00 (0 to 15)
ABS TAN ATAN AN00 (0 to 15)
(the second line will not be displayed)
+00000000.0
(the second line will not be displayed)
(2) Final numerical calculations
Final numerical calculations can be set at item e FINAL CALC RESULT on the conditions of
object types menu [OBJECT TYPE COND].
The setting procedure, error output settings, calculation sequence and parallel output based on
the output conditions are exactly the same as those used for item (1) individual numerical
calculations for each measuring programs.
