7-2
7
Setting and Operating Outlines
7-2 Screen specifications
[1] Operation (run) screen
Supply power to the IV-S20 main housing, and the MAIN OPS MENU (startup screen) will be
displayed on the monitor.
- Before applying the power, make sure that the power cable, monitor cable, camera cables, and
remote key pad have been connected to the IV-S20 main housing.
F L C1ALLC2NO ●
LOCK VX.X ■
C1=002.2 OK
C2=100.0 OK
(TYPE00)AREA1
OK
MEAS. XXXXXXms
MEAS0 CAM1 POS-DEVIATION
① ③
②
⑧
④
⑤
⑥
⑦
Select BUSY or READY on
the [I/O CONDITIONS]
menu.
①Object type No. (00 to 15) and the name assigned by the user for each object type
②Display of the results of the programmable output (auxiliary relay C116)
If C116 has not been set, the results of C112 are output. (See page 10·7)
③FLC1 ALLC2NO●
Display
OK
NG
"OK" is displayed when all of the individual evaluation results are acceptable.
"NG" is displayed if any single evaluation result is unacceptable.
(Error
message)
Description
Output monitor status
Camera 1 (C1)/camera 2 (C2) = All/upper/middle/lower/none
Image brightness: H = Original brightness of captured image
L = Brightness reduced to half that in the captured image
Image display mode: F = Freeze mode N = No camera input
④ LOCK VX.X ■
System program version number
Run menu lock ("LOCK" is not displayed while the screen is unlocked.)
⑤ C1＝002.2 OK
· This item is displayed when the illuminance monitor MONITOR LIGHT LVL on the
[OBJECT TYPE I/O] menu has been set to "YES." (See page. 9·115.)
⑥Measurement No. (0 to 3), camera No. (1 or 2) and measurement program name
Average density during measurement, and judgment (OK/NG)
Camera No. (C1 = camera 1, C2 = camera 2)
Flashes during communications
An error code and the measurement number that caused the error are
displayed on the upper line. The error message is displayed on the lower line.
X0〜6
:
Y0〜7
:
BUSY
:
MSR-CHNG REG-CHNG PC-MONTR SET-SCRN MANL-TYP-CHG
Operation status display: ●flashing = running, ◯ flashing = CCD trigger
sampling
⑨
