3-8
3
Operation Examples (Position measurement)
FC1H
1
[SYSTEM SETUP]
1OPS MENU SETTING
(TO NEXT SUB-MENU)
2OBJECT TYPE COND
(TO NEXT SUB-MENU)
3I/O CONDITIONS (TO NEXT SUB-MENU)
4ADJ. CAM POSITION
(TO NEXT SUB-MENU)
5DISPLAY MODE JAPANESE ENGLISH
6RECEIVING PARMS
EXEC
7INIT ALL PARMS EXEC
8SELF DIAGNOSTICS
EXEC
9SAVE IN FLASH MEM
EXEC
0OPERATIONS
Positioning mark
3-2 Position measurement
An example of the operation for measuring the deviation (from an absolute position) of a positioning mark
is shown below.
(1) Operation on the MAIN OPS MENU (after initialize all condetions)
1. Move the cursor to SET-SCRN item and press the SET key.
- The [SYSTEM SETUP] menu will be displayed.
(2) Operation on the [SYSTEM SETUP] menu
1. Move the cursor to 2 OBJECT TYPE COND (conditions of object type) and press the SET
key.
- [OBJECT TYPE COND] menu will be displayed.
Continued on the following page
MAIN OPS MENU
F L
C1ALLC2NO
VX.X
(TYPE00)
MEAS. ms
MEAS0 CAM1 NO
1
MSR-CHNG REG-CHNG PC-MONTR SET-SCRN MANL-TYP-CHG
X0~6
:
Y0~7
:
BUSY
:
