3-7
3
Operation Examples (Area measurement by binary conversion)
F L C1ALLC2NO
VX.X
(TYPE00)
OK
MEAS. XXXXXXms
MEAS1 CAM1 MEAS-BIN-AREA
REGST NO. 00(0~15)
AREA 001884 OK
Final evaluation result (*1)
Measuring time
Area (pixel count) and
evaluation result
[Display of the measured result]
MSR-CHNG REG-CHNG PC-MONTR SET-SCRN MANL-TYP-CHG
X0~6
:
Y0~7
:
BUSY
:
*2
Continued from the preceding page
(11) Measuring the area
Press the TRG/BRT key, and the size of the object in the image in the window will be displayed as
a pixel count.
*1 The final evaluation result will be displayed as "OK" in the upper left corner of the screen when
all of the items have been evaluated acceptable.
If there is a single unacceptable item, "NG" will be displayed.
When measuring an object area with the binary image, only the size of the object is measured.
If the object meets to the conditions specified in step (9) (within the range between the upper
and lower limit values), "OK" will be displayed.
*2 When the judgment result is OK, Y0 will be turned ON because we set it that way in step (9),
and a filled box will be displayed in the Y0 position at the bottom of the screen. (If the result
is NG, an empty box will be displayed in the Y0 position at the bottom of the screen.)
To Next Page
