Table of contents
Safety PrecautionsSafety Precautions
Organization of this manual
Chapter 1: Overview ............................................................................................. 1-1 to 7
1-1 Features 1-1
[1] Features of the CCD camera 1-1
[2] IV-S20 features 1-2
1-2 Measurement program 1-3
[1] Positional deviation/absolute position measurement 1-3
[2] Degree of match for shape and size 1-4
[3] Distance and angle measurement 1-4
[4] Lead inspection 1-5
[5] Area measurement by binary conversion 1-5
[6] Counting quantities by binary conversion 1-6
[7] Object identification (labeling) by binary conversion 1-6
[8] Existence inspection by point measurement 1-7
Chapter 2: Precautions for Use ...................................................................................2-1
Chapter 3 : Operation Examples........................................................................ 3-1 to 49
3-1 Area measurement by binary conversion 3-2
3-2 Position measurement 3-8
3-3 Degree of match inspection for shape and size 3-15
3-4 Distance measurement 3-22
3-5 Lead inspection 3-31
3-6 Existence inspection by point measurement 3-38
3-7 Position correction (example of point measurement) 3-44
3-8 Use of numeric calculations (example of shape and size inspection) 3-45
Chapter 4: System Configuration ....................................................................... 4-1 to 7
4-1 Basic system configuration 4-1
4-2 System configuration examples 4-4
[1] System configuration example for measurement triggered by an external trigger, such as a photo
sensor 4-4
[2] System configuration example for measurement triggered by the internal CCD sensor trigger 4-5
[3] System configuration example for measurement triggered by a command from a personal computer
4-7
Chapter 5: Part Names and Functions ............................................................... 5-1 to 5
5-1 IV-S20 main housing 5-1
5-2 Camera section 5-2
[1] Camera 5-2
[2] Cemera lens (IV-S20L16) 5-4
[3] Camera conversion cable (IV-S20HC3) 5-4
5-3 Remote key pad 5-5
C-1
