Setting and Operating Outlines
7-1 Setting and operating procedures
The setting and operating procedures are outlined below.
Chapter 7: Setting and Operating Outlines
1 System design (Ref. section)
· Measurement program (positional deviation
measurement, degree of match inspection, etc.)
· Number of cameras, externally connected devices,
system components
· Input/output (measurement start input, result
output, object type change, etc.)
· Lighting equipment, illumination, shutter speed, lens, etc.
1-2 Measurement programs
4-1 Basic system configuration
4-2 System configuration examples
Chapter 11 Input/Output Condi-
tions and Settings
6-1 Installation conditions
6-2 Connection and installation
methods
Chapter 7 Setting and Operating
Outlines
Chapter 11 Input/Output Condi-
tions and Settings
Chapter 11 Input/Output Condi-
tions and Settings
Chapter 14 Computer Link
Chapter 15 Troubleshooting
(Chapters 3, 7 to
12, 13 and 14)
Chapter 15 Troubleshooting
12-1 Settings
See the setting procedures start-
ing on page 9·1.
2 Installation/assembly
· Connection of cameras and monitor to the IV-S20 main
housing
· Installation of the IV-S20 main housing and camera body
· Connection of a power supply, input/output terminals
and external devices
3 Turning ON the power supply (the IV-S20 main housing and monitor)
4 Environment settings
· Input/output conditions related to external devices
(Communication conditions, shutter speed, lighting
monitor, output monitor)
5Setting the conditions for each object type
· Object type No. specification
· Edit (copy and initialization)
· Setting measurement program conditions
(measurement 0 to 3)
· Setting positional correction “YES/NO”
· Setting system total numerical calculations
· Setting final output conditions
· Setting system/input/output
6Other settings
7 Operation
8Test/inspection
9 Maintenance
· Japanese/English display switching, all parameter recei-
ving, total initialization, saving to flash memory, etc
Chapter 8 Run Menu Condi-
tions and Settings
Chapter 9 Setting the Condi-
tions for Each
Object Type
Chapter 10 PC Functions
6-3 Equipment connections
To Next Page
