12-4
12
Other Settings and Operations
[4] Saving to flash memory
All the data entered on the [SYSTEM SETUP] menu and sub-menus (OPS MENU SETTING, OBJECT
TYPE COND, I/O CONDITIONS, and ADJ.CAM POSITION menus) are saved in the IV-S20 flash
memory.
- If the power is disconnected from the IV-S20 main housing, or if the object type number is
changed before the data is saved in the flash memory, the data will be deleted.
[Operating procedure]
1. Move the cursor to item 9 SAVE IN FLASH MEM. (save data in flash memeory) with the up and
down keys, and press the SET key.
- The following message will be displayed on the upper part of the screen.
2. Press the SET key.
-The data saving will start, and the progress will be displayed on the bottom of the screen.
When the data has been saved in the IV-S20 flash memmory, the display will change from
"SAVING" (saving) to "SAVING COMPLETE" (complete saving).
Note:
- If the ESC key is pressed, the set data entered will not be saved in the IV-S20 flash memory.
In this case, if the power to the IV-S20 main housing is turned OFF, or if the object type No. is
changed, the data will be deleted.
- The set data you have entered can be saved in the IV-S20 flash memory by moving the cursor to item
0 OPERATIONS on the [SYSTEM SETUP] menu and pressing the SET key.
DATA SAVE? (Do you want to save data?) (YES=[SET]/NO=[ESC])
1
[SYSTEM SET UP]
1OPS MENU SETTING (TO NEXT SUB-MENU)
2OBJECT TYPE COND (TO NEXT SUB-MENU)
3I/O CONDITIONS (TO NEXT SUB-MENU)
4ADJ. CAM POSITION (TO NEXT SUB-MENU)
5DISPLAY MODE JAPANESE ENGLISH
6RECEIVING PARMS EXEC
7INIT ALL PARMS EXEC
8SELF DIAGNOSTICS EXEC
9SAVE IN FLASH MEM EXEC
0OPERATIONS
On the [MAIN OPS MENU], move the cursor to SET-SCRN, and press the SET key.
REFERENCE IMAGE
SYSTEM I/O
OBJECT TYPE DATA
■■■□□□□□
□
□
SAVING
