3-2
3
Operation Examples (Area measurement by binary conversion)
Object to be measured (white)
FC1H
1
[SYSTEM SETUP]
1OPS MENU SETTING
(TO NEXT SUB-MENU)
2OBJECT TYPE COND
(TO NEXT SUB-MENU)
3I/O CONDITIONS (TO NEXT SUB-MENU)
4ADJ. CAM POSITION
(TO NEXT SUB-MENU)
5DISPLAY MODE JAPANESE ENGLISH
6RECEIVING PARMS
EXEC
7INIT ALL PARMS EXEC
8SELF DIAGNOSTICS
EXEC
9SAVE IN FLASH MEM
EXEC
0OPERATIONS
3-1 Area measurement by binary conversion
An example of area measurement is given using the following object. The area will be measured by
counting the number of pixels after binary conversion.
(1) Operation on the MAIN OPS MENU (after initialize all conditions)
1. Move the cursor to SET-SCRN item using the left and right keys, and press the SET key.
- The [SYSTEM SETUP] menu will be displayed.
(2) Operation on the [SYSTEM SETUP] menu
1. Move the cursor to 2 OBJECT TYPE COND (conditions of object type) using the up and
down keys, and press the SET key.
- The [OBJECT TYPE COND] menu will be displayed.
Continued on the following page
1
F H
C1ALLC2NO
VX.X
(TYPE00)
MEAS. ms
MEAS0 CAM1 NO
MSR-CHNG REG-CHNG PC-MONTR SET-SCRN MANL-TYP-CHG
X0~6
:
Y0~7
:
BUSY
:
MAIN OPS MENU
