9-90
Counting quantities by binary convension
9
Convert it to a
binary image
Capture an image
Measure the number of
objects/total area
Objects
Purpose
Example
Checks the number of objects (max. 3000 pcs.) when there is more than one object
in an image. Measurement of the object's position is optional.
· When the specified pixel field has been converted to a binary image, the white
areas are measured or identified as separate objects and counted.
Counting the number of food products or parts.
[Measurement result]
· Number of objects/total area
· Inspection sequence
Application
9-8 Counting quantities by binary conversion
