9-32
9
Shared settings
3
4
1
2
[OBJECT TYPE COND]
1OBJECT TYPE NO.
00(0~15)
2EDIT
COPY(←OBJTYPE00) INITIALIZE
3TITLE REGISTRATION
(TO NEXT SUB-MENU)
4MEAS.0, CAMERA1
NO (TO NEXT SUB-MENU)
5POS. ADJ.CAMERA1 NO ADJ. [
REG. 0-1PNTSXY］
6MEAS.0, CAMERA2
NO (TO NEXT SUB-MENU)
7POS. ADJ.CAMERA2 NO ADJ. [
REG. 0-1PNTSXY］
8SELECT CAMERA IMG
NO CAM1 CAM1 CAM1&2
9COMPARE IMAGES
NO SUB.I1−T1 DIFF.ABS｜I1−T1｜
0MEASUREMENT 1
NO (TO NEXT SUB-MENU)
qMEASUREMENT 2
NO (TO NEXT SUB-MENU)
wMEASUREMENT 3
NO (TO NEXT SUB-MENU)
eFINAL CALC RESULT
(TO NEXT SUB-MENU)
rFINAL OUTPUT COND
(TO NEXT SUB-MENU)
tSYSTEM-IN/OUT
(TO NEXT SUB-MENU)
yHALT MEAS ON NG
NO YES
uUPPE
R MENU
· Item 9 COMPARE IMAGES, will be displayed unless
item 8 SELECT CAMERA IMG, is set to NO.
On the MAIN OPS MENU, move the cursor to SET-SCRN item, and press the SET key.
-On the [SYSTEM SETUP] menu, move the cursor to 2 OBJECT TYPE COND
(condition of object type) and press the SET key.
- Do not disconnect the power while IV-S20 is initializing.
The set data other than currently initializing may be corrupted. Unless all of the data is
initialized it will not be possible to restart the machine (i.e. partial initialization is not possible).
Note
(2) Initialize measurement condition of each type
The measurement conditions for a specified object type (data for the object type you are in the
process of entering) will be initialized.
[Operation procedure]
1.Select item 1 OBJECT TYPE NO. (object type number) using the up and down keys and press
SET key.
2.Select the object type number (00 to 15) to be initialized using the up and down keys.
3.Select item 2 EDIT, using the up and down keys and press SET key.
4.Select EXEC.INIT (start initialization) using the up and down keys and press SET key.
- While the initialization is in progress, the message "Initialization of data is in progress" will
appear at the top of the screen. When the initialization is complete, this message will
disappear.
