Positional deviation measurement
9
[OBJECT TYPE COND
(conditions for object types)]
eFINAL CALC RESULT
(final numerical calculations)
(see 9-2 [4])
[OBJECT TYPE COND
(conditions for object types)]
rFINAL OUTPUT COND
(final output conditions)
(see "PC function" in
Chapter 10)
Conditions for gray scale search
Conditions for gray
scale search
Mode
1 or 2 point search
1 or 2 point edge
1 point search
+ 1 point edge
Conditions for edge detection
Conditions for edge detection
1SELECT MEAS. TYPE
(Select MEAS-POSITION-
DEVIATE) (positional
deviation measurement)
2COPY,
3INITIALIZATION
(copy, initialization)
(see section 9-2, [7], [8])
5EVALUATION COND
(evaluation conditions)
6NUMERIC CALC COND
(conditions for numeric calculation)
7OUTPUT CONDITIONS
(output condition)
4MEAS. PROG. COND
(conditions for measurement
programs)
MAIN OPS MENU
These settings are found in the [TYPE00-MEAS0]
(object type - measurement 0) menu
[MAIN OPS MENU]
SET-SCRN
[SYSTEM SETUP]
2OBJECTTYPE COND
(conditions for object types)
[OBJECT TYPE COND (conditions for
object types)]
4MEAS.0 CAMERA 1
(measurement 0, camera 1)
6MEAS.0 CAMERA 2
(measurement 0, camera 2)
[1] Setting sequence
