Degree of match inspection
9
Continued from the previous page
Continued on the following page
Return to the MAIN OPS MENU
DEL.
[OUTPUT CONDITIONS]
(TYPE00-MEAS.1-DEG OF MATCH)
1PAGE NO.
0(0~4) REG.NO YES
2SET POSITION
MOVE
3INPUT SIGNAL
REGT.NO.00(0~15)
MATCH.M0(0~1) CRD-X0(0~1) CRD-Y0(0~1)
LVL G0(0~1)
CAL N00(0~15) AUXRLYC000(0~127)
4LOGIAL SYMBOL
5OUTPUT SIGNAL
AUX.RLYC000(0~127) DEL.
6UPPER MENU
[PAGE0]
INPUT0
LOGIC
INPUT1
LOGIC
INPUT2
LOGIC
INPUT3
LOGIC
10 234567OUT
The numbers ranging from 00 to 15 in front of the characters are registration numbers.
· The input signals which may be set depend on the selection made at item 3 as follows.
· For more information on output conditions see “the PC Function”, in Chapter 10.
3INPUT SIGNAL
Degree of match M
Coordinates X/Y
Light level G
Calculation N
Auxiliary relay C
Model 0
00M0 to 15M0
00X0 to 15X0/00Y0 to 15Y0
00G to 15G
N00 to N15
C000 to C127
Model 1
00M1 to 15M1
00X1 to 15X1/00Y1 to 15Y1
00G to 15G
