Sharp IV-S20 User Manual

9-100
Object identification (labeling) by binary conversion
9
1 REGST NO.
(registration number )
2 BINARY AREA COND
(condition for binary areas) 
3 FIND CENT/GRAVITY
(center of gravity
measurement)
4MAIN AXIS ANGLE
5FILLET DIAMETER
(fillet width)
6PERIMETER LENGTH
(circumference)

Mesurement conditions
Set this to any number from 0 to 3 and select NO or
YES to store it.
Setting details
- Select LABEL-BIN-OBJ (object identification by binary conversion) in
item 1.
- Item 2 will be displayed unless NO is selected in item 8 SELECT CAMERA IMG
(camera selection) which is in the [OBJECT TYPE COND] (conditions of object type)
menu.
Continued on the following page
Select item 6 MEAS.PROG.COND (conditions for measurement programs).
Select item2 BINARY AREA COND (conditions for binary areas).
On the MAIN OPS MENU, move the cursor to SET-SCRN, and press SET key.
-On the [SYSTEM SETUP] menu, move the cursor to 2 OBJECT TYPE COND (conditions of
object type) and press the SET key.
 -Select item 0 MEASUREMENT 1, q MEASUREMENT 2 or w MEASUREMENT 3
on the [OBJECT TYPE COND] menu .
[TYPE00-MEAS1]
1MEAS SELECTION NO CHECK-DEG-OF-MATCH 
DST&AGL MES . ( GRAY&EDGE GRAV)
INSPECT-LEAD MEASR-BIN-AREA
CNT-BIN-OBJ LABEL-BIN-OBJ
POINT MEAS
2COMPARE IMAGES NO YES(CAM1) 
3SELECT CAMERA CAM1 CAM2
4COPY EXEC←TYPE00 − MEAS1 − NO
5INITIALIZATION EXEC
6MEAS.PROG. COND (TO NEXT SUB-MENU)
7EVALUATION COND (TO NEXT SUB-MENU)
8NUMERIC CALC COND (TO NEXT SUB-MENU)
9OUTPUT CONDITIONS (TO NEXT SUB-MENU)
0UPPER MENU
- If YES was specified in item 1REGST NO. (registration number), then items 2 to 6 will be
displayed.
[MEASURING COND] (TYPE00-MEAS.1-LABEL-BIN-OBJ)
1REGST NO. 00(0~3) REG.NO YES
2BINARY AREA COND (TO NEXT SUB-MENU)
3FIND CENT/GRAVITY NO YES
4MAIN AXIS ANGLE NO YES
5FILLET DIAMETER NO YES
6PERIMETER LENGTH NO YES
7UPPER MENU
This will return you to the [TYPE00-MEAS1 to 3] menu.
Select YES/NO for each of the measurements.
-See page 9Æ102.
The conditions for binary areas are set on the next
menu.
7UPPER MENU
This is how the line
looks when the ob-
ject type is set to
00 and the selec-
ted measurement
is 1.
[2] Setting details
An explanation of the 6 MEAS.PROG.COND (conditions for measurement programs) from the
[TYPE00-MEAS1 to 3] (object type measurement) menu.
