Continued from the previous page
Continued on the following page
Return to the [TYPE00-MEAS1 to 3] (object type measurement) menu and select item 8 NUMERIC CALC COND
(numerical calculation conditions).
Select item 7 EVALUATION COND (evaluation condition) on the [TYPE00-MEAS1 to 3] menu.
These displays can be set using
the up and down keys. (The
choices are NO, Y0 to 7, C000 to
C127).
Evaluation conditions
Setting details
3 TOTAL AREA
(total surface area)
Set the range for the number of objects that will produce an
OK evaluation.
This will return you to the [TYPE00 to MEAS1 to 3] menu.
6 MAKE A TEST
RUN
7 UPPER MENU
Pressing the SET key will test the evaluation conditions, display
the test results.
4 LABEL NUM
5 OBJ-AREA
After performing a MAKE A TEST RUN at item 6, and a label
number is entered, the results displayed in item 5 will change.
Enter the maximum label size (area) that will produce an OK
result.
· The center of gravity/main axis angle/fillet width/perimeter will
be displayed when measurement is set to YES on the
[MEASURING COND] menu.
· Items 2 to 6 will be displayed if REGST NO. (registration number) is set to YES on the
[MEASURING COND] (measurement conditions) menu.
After performing a MAKE A TEST
RUN at item 6, the number of
objects identified will be displayed
in item 4.
[EVALUATION COND]
(TYPE00-MEAS.1-LABEL-BIN-OBJ)
1REGST NO. 0(0~3)
[
TEST RESULT]
[
OUT]
2NUMBER 000~128 006 OK NO
3TOTAL AREA 000000~245760 008276 OK NO
4LABEL NUM 000(0~ 005 )
5OBJ-AREA 000000~245760 001415 OK NO
GRAVITY (206.0,303.0)
AXIS-ANGL -38.0゜
FILLT-DIA X=042 Y=030
PERIMETER 00138.8
6MAKE A TEST RUN
(SET KEY)
7UPPER MENU
· Set the maximum number of objects/total area/area per label after checking the test results from
item 6 MAKE A TEST RUN.
· For more information about evaluation conditions, see section 9-2 [3] Evaluation conditions.
1 REGST NO.
(registration number)
Enter a number from 0 to 3.
2 NUMBER
(number of objects)
Set the range for the total area that will produce an OK
evaluation.
To Next Page
