Newly added functions on software version 2.01 (compared with version 2.0)
Operation screen
Item Additional function Reference page
Latch the measurement results on the operation
screen after resetting the power.
Description of
paragraph 9 on
page 7-2 to 7-3
Object type
change
When the measurement start input is general-purpose
serial input, the object type can be changed using the
type number specification instruction
(processing code 55).
11-7 and 13-1.
Detalis about the improved functions in software version 2.02 (compared with version 2.01)
Lead inspection
Computer link
Binary processing
Communication
(general-purpose se-
rial) computer link
Item Improved functions
Reference page
Computer link
9-51, 9-62
9-85, 9-93
9-101, 9-109
9-72
11-18, 14-24
13-20, 14-12
13-19, 14-11
14-8 to 10
Increased number of leads the can be inspected (from 64 to 128 pins max.)
"Form 4" has been added to the control procedures, and a "QW" command
has been added to the block write commands when the Mitsubishi is set.
Parallel input X5
11-1
The reference image registration function, using input terminal X5, has
been extended to make it available with camera 2.
Change between
the Japanese and
English display
modes
12-1
The menu display details in the English display mode have totally
changed.
Auxiliary relay C112
Auxiliary relay C114
10-7
Binary image displays are set to "Yes" and the [MAIN OPS MENU] , the
measuring time is reduced.
[ Example of the measuring time ]
Blocks 60 to 77 have been added to the "Label measurement after binary
conversion" operation.
Changed data order for the block 0 of "Label measurement after binary conversion ".
VAR-RATE (variation rate) has been added to the THRSHLD-ADJ.
Changed data order for the masurement programs
- Block 2 in distance and angle measurements, block 0 in lead
inspection, block 0 in area measurement by binary conversion, block 0
in label measurement after binary conversion.
Changed functions of the auxiliary relays C112 (final evaluation result)
and C114 (CCD trigger status output).
- Measurement conditions
Capture all images, registered window number = 1
Measurement window = Rectangle, upper left coordinates (0, 0),
lower right coordinates (511, 239)
Mask window = Rectangle, upper left coordinates (0, 0),
lower right coordinates (255, 119)
- Measuring time
When the shutter speed is 1/60 sec., the measuring time is reduced
from 143 ms (version 2.01) to 101 ms (version 2.02).
When the shutter speed is 1/1000 sec., the measuring time is
reduced from 127 ms (version 2.01) to 85 ms (version 2.02).
Area measurement
by binary conversion
Counting quantity
by binary conversion
