Appendix-6
App
Note : In version 2.0, selection numbers are counted from 0 compared with version 1.6.
(except camera numbers)
Item Ver. 2.0 Ver. 1.6 or earlier
Others
Added calculation functions for comparison between
registered images and captured images [(balance
absolute value)/(balance value)]
Added calculation function for comparison between
camera 1 image and camera 2 image [(balance absolute
value/(balance value)]
Windows can be set in units of one pixel (in units of 4
pixles for a gray search)
Introduced pop-up menus for screen display
Can display binary images
Can display programmable OK/NG
Displays "COMMUNICATING" (indicates that the IV-S20
is currently communicating)
Displays input terminals
Displays numerical calculation results
Measurement number selectable from X5 and X6
Select between BUSY and READY outputs
Added evaluation using average density from CCD trigger
Shutter speed can be set for each object type
Shutter speed can be set continuously
Possible to test using the through image
Store monitor brightness level setting in flash memory
No calculation functions for comparison
No calculation functions for comparison
In units of 8 pixels (in units of 32 pixels
for object identification)
Only dark and bright image
No OK/NG display
No display
No display
No display
Not available
BUSY output only
Area only after binary conversion
One time for all types
Fixed value only
Only available in version 1.6
No storing in flash memory
Object type numbers
Measurement program numbers
Setting numbers for each menu
(such as registration numbers,
mode numbers etc.)
Ver. 2.0
Ver. 1.6 or earlier
0 to 15
1 to 16
Measurement 0 to 3
Measurement 1 to 4
Start at 0
Start at 1
