3-32
3
Operation Examples (Lead inspection)
Continued from the preceding page
(3) Operation on the [OBJECT TYPE COND] (conditions of object type) menu
1. Move the cursor to 0 MEASUREMENT 1 with the up and down keys, and press the SET key.
- The [TYPE00-MEAS1] (type: 00, measurement: 1) menu will be displayed.
(4) Operation on the [TYPE00-MEAS1] menu
1. Move the cursor to 1 MEAS SELECTION (selection of measurement) with the up and down
keys, and press the SET key.
2. Move the cursor to INSPECT-LEAD (lead inspection) with the right and left keys, and press the
SET key.
3. Move the cursor to 6 MES.PRG.COND (conditions of measurement program) with the up
and down keys, and press the SET key.
- The [MEASURING COND] (measurement condition) menu will be displayed.
(5) Operation on the [MEASURING COND] menu
1. Move the cursor to 1 REGST NO. (registration number) with the up and down keys, and press
the SET key. Move the cursor to YES with the right and left keys, and press the SET key.
- The item 2 will be displayed.
2. Move the cursor to 2 SEARCH CRITERIA (criteria search condition) with the up and down
keys, and press the SET key.
- The gray scale search matching setting menu, image window, and search window will be displayed.
Continued on the following page
1
FC1H
[OBJECT TYPE COND]
1OBJECT TYPE NO.
00(0~15)
2EDIT
COPY(←OBJTYPE00) INITIALIZE
3TITLE REGISTRATION
(TO NEXT SUB-MENU)
4MEAS.0, CAMERA1
NO (TO NEXT SUB-MENU)
5POS. ADJ.CAMERA1 NO ADJ. [
REG. 0-1PNTSXY］
6MEAS.0, CAMERA2
NO (TO NEXT SUB-MENU)
7POS. ADJ.CAMERA2 NO ADJ. [
REG. 0-1PNTSXY］
8SELECT CAMERA IMG
NO CAM1 CAM1 CAM1&2
0MEASUREMENT 1
NO (TO NEXT SUB-MENU)
qMEASUREMENT 2
NO (TO NEXT SUB-MENU)
wMEASUREMENT 3
NO (TO NEXT SUB-MENU)
eFINAL CALC RESULT
(TO NEXT SUB-MENU)
rFINAL OUTPUT COND
(TO NEXT SUB-MENU)
tSYSTEM-IN/OUT
(TO NEXT SUB-MENU)
yHALT MEAS ON NG
NO YES
uUPPE
R MENU
1
3
2
[TYPE00-MEAS1]
1MEAS SELECTION
NO CHECK-DEG-OF-MATCH
DST&AGL MES
. (
GRAY&EDGE GRAV)
INSPECT-LEAD MEASR-BIN-AREA
CNT-BIN-OBJ LABEL-BIN-OBJ
POINT MEAS
3SELECT CAMERA
CAM1 CAM2
4COPY
EXEC←TYPE00
−
MEAS1
−
NO
5INITIALIZATION
EXEC
6MEAS.PROG. COND
(TO NEXT SUB-MENU)
7EVALUATION COND
(TO NEXT SUB-MENU)
8NUMERIC CALC COND
(TO NEXT SUB-MENU)
9OUTPUT CONDITIONS
(TO NEXT SUB-MENU)
0UPPER MENU
1
2
1
[MEASURING COND]
(TYPE00-MEAS1-INSPECT LEAD)
1REGST NO. 0(0~3) REG.NO YES
2SEARCH CRITERIA
(TO NEXT SUB-MENU)
3OBJ NO. FOR MEAS
CRT.0-0(0~7) REG.NO YES
6UPPER MENU
