Page #14 background image
6
1.7 Combinations of Servo Drive and Servo Motor
1.8 Servo control mode
Control Mode
Sign
Description
Basic
Position with
external command
Pt
Drive receives the pulse commands of a superior controller then runs
the motor to reach the assigned position.
Position with inner
command
Pr
According to the parameters setting and DI signals, drive runs the
motor to reach the assigned position.
Speed
S
Drive runs motor to attain the target speed. The command type which
is an analog voltage or the inner registers could be switched by DI.
Torque
T
The drive receives the commands to run the motor to generate the
demanded torque. The command source is the analog voltage.
Switched
Pt-S
Pt/S is switched mutually via the LOP signal of DI.
Pt-T
Pt/T is switched mutually via the LOP signal of DI.
Pr-S
Pr/S is switched mutually via the LOP signal of DI.
Pr-T
Pr/T is switched mutually via the LOP signal of DI.
S-T
S/T is switched mutually via the LOP signal of DI.
Servo drive
Servo motor (Note)
Low inertia series
Medium inertia series
SDE-010A2
SME-L005
-
SDE-010A2
SME-L010
-
SDE-020A2
SME-L020
-
SDE-040A2
SME-L040
-
SDE-075A2
SME-L075
-
SDE-100A2
SME-L100
SME-M100
SDE-150A2
SME-L150
SME-M150
SDE-200A2
SME-L200
SME-M200
SDE-300A2
SME-L300
SME-M300
