10.4.2. Dimensions of motors (2000rpm rated speed)
SME-
□□□□20XYZU
Items dimension (mm)
WF
φS
φF
LA
LB
LF
LR
MH
LM(*)
FC
HB
L100
130
3
55
11
50
113
127
(161)
145
4-φ9.0
L150
141.5
(175.5)
L200
156
(190)
L300
185
(219)
M100
130
3
55
11
50
113
127
(161)
145
4-φ9.0
M150
141.5
(175.5)
M200
176
3
78
18.5
74
139
139
(189)
200
4-φ13.5
M300
169
(219)
Note: ( ) inside value indicates the length of servo with electromagnetic brake.
