11.4. Correct use
Use these devices within specifications (voltage, temperature, etc. Refer to section 10.1 for details.).
(1) Power wiring: For UL/CSA specification, use only copper wires rated at 75 °C for wiring.
Drive
Wire: AWG (mm
2
)
R, S, T
L1, L2
U, V, W, PE
P, D, C, N
SDE－010A2U
AWG14 (2)
AWG14 (2)
AWG14 (2)
AWG14 (2)
SDE－020A2U
SDE－040A2U
SDE－075A2U
SDE－100A2U
SDE－150A2U
AWG12 (3.5)
AWG12 (3.5)
SDE－200A2U
SDE－300A2U
AWG10 (5.5)
AWG10 (5.5)
(2) Terminal block fixed torque: The crimping terminals must be suitable for UL specification, be with
insulating tube to prevent contact directly.
Drive
Recommended Torque: in-lbs (Nt-m)
R, S, T
U, V, W,
L1, L2, P, D, C, N
PE
SDE－010A2U
7.1~10.5 (0.8~1.2)
12 (1,4)
SDE－020A2U
SDE－040A2U
SDE－075A2U
SDE－100A2U
SDE－150A2U
12 (1,4)
7.1~10.5 (0.8~1.2)
SDE－200A2U
SDE－300A2U
(3) Selection example of MCCB:
Drive
UL Listed Current Limiting Circuit
Breaker Rating
Selection example
SDE－010A2U
240V, 5A
NF50-SVFU-5A
SDE－020A2U
SDE－040A2U
240V, 10A
NF50-SVFU-10A
SDE－075A2U
240V, 15A
NF50-SVFU-15A
SDE－100A2U
SDE－150A2U
240V, 30A
NF50-SVFU-30A
SDE－200A2U
SDE－300A2U
