4.5.1. Indication of external I/O signals
This display is used to verify the ON/OFF states of digital I/O signals connected to the drive.
(1) Operation
Call the display screen after power on. Press the “MODE” key to show the diagnostic screen:
(2) Display of I/O pin definition
The figure above as an example: DI1 to DI8 are “ON” status. DI9 and DI10 are ”OFF” status.
DO1 to DO5 are “ON” status, DO5 and DO6 are “OFF” status.
Connector
Pin No.
Input/
output
Pt
Pr
S
T
CN1
12
I
TL1
POS4
TL
TL
13
I
CDP
POS5
CDP
CDP
14
I
SON
SON
SON
SON
15
I
CM1
POS1
SP2
SP2
16
I
PC
POS2
ST1
RS2
17
I
TL
CTRG
ST2
RS1
18
I
RES
RES
RES
RES
19
I
CR
CR
SP1
SP1
20
I
EMG
EMG
EMG
EMG
21
I
LOP
POS3
LOP
LOP
22
I
LSP
LSP
LSP
LSP
23
I
LSN
LSN
LSN
LSN
41
O
INP
INP
SA
WNG
42
O
ZSP
ZSP
ZSP
ZSP
43
O
CMDOK
CMDOK
MBR
MBR
44
O
TLC
TLC
TLC
VLC
45
O
RD
RD
RD
RD
46
O
ALM
ALM
ALM
ALM
