7.4. Relevant parameter settings of PR
Speed command: PF33~PF48, total 16 sets.
Bit
15~0
PF33~PF48
1~3000rpm
Acceleration/Deceleration time: PF49~PF64, total 16 sets.
Bit
15~0
PF49~PF64
1~65500ms
Delay time: PF65~PF80, total 16 sets.
Bit
15~0
PF65~PF80
1~32767ms
Relevant parameter settings
Description
PA04
Home moving option
PA08
Home moving high speed option 1
PA09
Home moving high speed option 2
PE01
Origin return definition
PE02
Origin offset value definition
PF81
Protection trigger deceleration time
PF82
PR trigger register
PF86
Software forward stroke limit
PF87
Software reverse stroke limit
PE03~PE98
PATH#01~ PATH#48 stroke settings
PF01~PF30
PATH#49~ PATH#63 stroke settings
