10.3. Motor specifications
10.3.1. Low inertia, small capacity motor specifications
SME-□□□□30XYZU
--
L005
L010
L020
L040
L075
Flange
mm
40
60
80
Rated output capacity
W
50
100
200
400
750
Rated torque (*1)
Nm
0.16
0.32
0.64
1.27
2.4
Maximum torque
Nm
0.48
0.96
1.92
3.81
7.2
Rated speed
rpm
3000
Maximum speed
rpm
6000
Rated current
A
0.85
0.85
1.7
2.8
5.8
Maximum current
A
2.7
2.7
5.2
9.0
18.5
Rotor inertia J (x10
-4
) (*2)
kg-m
2
0.0295
(0.0299)
0.0518
(0.0523)
0.161
(0.178)
0.277
(0.294)
1.07
(1.11)
Continuous running power
kw/s
8.6
19.6
25.2
58.5
53.3
Installation mental plate size
mm
250 x 250 x 6
Isolation class
-
CE(B) & UL(A)
Isolation impedance
-
100MΩ @ DC500V
Isolation withstand voltage
-
60sec @ AC1500V
Encoder resolution
-
Singe turn 22bit (4,194,304 Pulse); multi turn 16bit (65,536 turns)
Structure (*3)
-
Totally enclosed, natural cooling (IP rating: IP65)
Vibration rank
-
V-15
Environment
Surrounding temperature
-
0 °C to 40 °C (non-freezing) / storage: -15 °C to 70 °C (non-freezing)
Surrounding humidity
-
80 %RH maximum (non-condensing) / storage: 90 %RH maximum (non-condensing)
Altitude
-
1000 m or less above sea level
Environment condition
-
Indoors (no direct sunlight); no corrosive gas, inflammable gas, oil mist or dust
Vibration resistance
-
X/Y: 5G
Shaft (*5)
Fd
mm
20
25
35
Radial Fr
N
68.6
245
392
Axial Fa
N
39.2
98
147
Electromagnetic brake (*4)
Input voltage
V
DC 24V ± 10%
Brake torque
Nm
0.3
1.3
2.4
Power consumption
W
6.3
7.9
8.6
Current consumption
A
0.24
0.32
0.35
Impedance at 20°C
Ω
92.4
75.4
67
Release time
ms
20
30
50
Bind time
ms
20
20
20
Weight (*2)
Kg
0.33
(0.55)
0.45
(0.67)
0.85
(1.23)
1.23
(1.59)
2.24
(2.87)
