Page #237 background imageLoading...
Page #237 background image
229
12.2. Brake resistor
(1) Built-in brake resistor and relevant parameters
Drive type
Built-in resistor
Resistance(Ω)
Capacity(W)
PA10 setting
PA11 setting
SDE-010A2
100
20
100
500
SDE-020A2
100
20
100
500
SDE-040A2
100
20
100
500
SDE-050A2
100
20
100
1000
SDE-075A2
40
40
40
1000
SDE-100A2
40
40
40
1000
SDE-150A2
13
100
13
1000
SDE-200A2
13
100
13
1000
SDE-350A2
13
100
13
1000
(2) Relevant parameter setting and specification of external brake resistor
To confirm that P and D terminal are in open-circuit status and that P and C terminal are connected
with the external brake resistor.
Drive
External brake resistor recommendation
Brake resistor
part No.
Permissible Min.
resistance
(Ω)
Capacity
(W)
PA10
PA11
SDE-010A2□□
100
300
100
300
ABR-300W100
SDE-020A2□□
100
300
100
300
ABR-300W100
SDE-040A2□□
100
300
100
300
ABR300W100
SDE-075A2□□
40
500
40
500
ABR-500W40
SDE-100A2□□
40
500
40
500
ABR-500W40
SDE-150A2□□
13
1000
13
1000
ABR-1000W13
SDE-200A2□□
13
1000
13
1000
ABR-1000W13
SDE-300A2□□
13
1000
13
1000
ABR-1000W13
